The AOF is designed to protect the compressor from dirt and all solid contaminants including metallic magnetic particles. It is ideal for burnout/clean-up situations. Select models contain desiccant for moisture removal.

Features & Benefits

• Stainless Steel Power Element Eliminate Corrosion and Prevent Valve Failure
• Replaceable Power Element
• External Superheat Adjustment
• Balanced Port Construction Compensates for Changes in Operating Pressures Due to Varying Ambients or Widely Varying Evaporator Loads
• Bi-Directional Control Capability
• External Equalizer

Specifications

• Type: Balanced Port, Bi-Directional, Adjustable Superheat, Straight Through
• Nominal Size: 7/8 Inch x 1-1/8 Inch
• End Connection: ODF Soldered x ODF Soldered
• End to End Distance: 5 Inch
• Pressure Rating: 450 PSIG
• Inclusions/Features: 1/4 Inch ODF Soldered External Equalizer, Stainless Steel Power Element, Replaceable Power Assembly
• Exclusions: Bleed Hole
• Application: Large Tonnage Heat Pump, Air Conditioner and Commercial Refrigerant
Capillary Tube Length 10 Foot; Refrigerant Type R-410A; Capacity 16 Ton; Charge Code Wide Range; Height 4.49 Inch
