Features & Benefits

• Provides Fast and Easy Indication of High System Moisture Content Lack of Subcooling or Low System Charge Liquid Level in Receiver
• Oil Level in Compressor
• Type “N” Provides Optimal Moisture Indication for Refrigerant
• All Indicators are Dirt Resistant
• Available in Both Inline and Vessel Mount Versions
• Hermetically Sealed, Tempered Glass for Easy Viewing

Specifications

• Type: N-Type, Low Pressure
• End Connection: 1/2 Inch Flare x 1/2 Inch Flare
• End to End Distance: 2.323 Inch
• Body Material: Brass
• Temperature Rating: -58 to 175 Deg F
• Pressure Rating: 500 PSIG
• Application: Indicate the Condition of the Refrigerant in the Liquid Line
• Applicable Standard: UL (Canada and US), EAC
• Connection Material Brass
