25HP 1800RPM 230/460V ODP
25HP 1800RPM 230/460V ODP
Description
ABB Motors and Mechanical Inc. (Baldor-Reliance) 25 HP, 230/460 VAC 60 Hz 3-Phase, 60/30 A, 1760 RPM, B Insulation, Steel 284T Frame, F1 Mount Arrangement, Reversible, 4-Pole, 1-Speed, ODP, General Purpose AC Motor
Specifications
- Enclosure Type: ODP
- Power Rating: 30 HP
- Voltage Rating: 230/460 Volt AC 3-Phase
- Frequency Rating: 60 Hertz
- Motor FLA: 37 Amp
- Number of Speeds: 1
- Speed Rating: 1775 RPM
- Reversible: Yes
- Service Factor: 1.15
- Efficiency: 93 Percent
- NEMA Frame Size: 286T
- Insulation Class: F
- Frame Material: Steel
- Application: General Purpose Overall Length 25.06 Inch; Motor Type 4048M; Base Indicator Rigid; Mounting Arrangement F3; Pulley End Bearing Type Ball; Pulley Shaft Indicator Standard; Starting Method Direct on Line; Number of Poles 4; Power Factor 82; Temperature Rating 40 Deg C
Specifications
- BrandBaldor
- HP25
- Line Voltage (60Hz)480V
- TypeBlower Motor
- Shipping Weight226 lb
- UL ListedFalse
- UL RecognizedFalse
