Features & Benefits

• ZoomLock Fitting are Specially Designed to Work without Brazing which Automatically Makes Job Simpler and Faster when Joining Copper Tube
• The 1-Piece Fitting are Reliably Secure, Leakproof and More Repeatable than Brazed Connection
• The Biggest Benefit of that Improved Efficiency is More Productivity and Increased Profit Potential, But there are also Many Other Exciting Advantages to Braze-Free Tube Connecting
• Less Equipment and No Gas Needed
• Safer Condition, No Fire Hazard
• No Hot Work Permit Required More Environment-Friendly
• No Solder-Related Quality Issues
• No Need to Nitrogen Purge
• Made in USA

Specifications

• Type: Flame-Free, Straight
• Nominal Size: 3/4 Inch x 3/4 Inch x 3/4 Inch
• End Connection: ZoomLock x ZoomLock x ZoomLock
• Material: Copper
• Material Specification: ASTM B75/B743
• Pressure Rating: 700 PSI
• Temperature Rating: 250 Deg F
• Application: High Pressure HVAC/R System, Glycol, Non-Potable Water, Air Conditioning, Refrigeration, Transportation, Heat Pump
• Applicable Standard: UL (Canada and US), UL 207/109, ASHRAE-15, ANSI 15/31.5, ASME B31.5, TUV, ICC-ES, PMG-1296, CRN
• O-Ring Temperature Rating -40 to 300 Deg F
• Includes HNBR O-Ring
