Features & Benefits

• 1 Gallon Collection Tank
• 1/50 HP, Fan Cooled, Concentric Motor
• Vertical Centrifugal Pump Design
• Automatic Start and Stop Operation
• Float (Solid Polymer) Activated Switch for Automatic High Level Water Detection (Overflow Detection Switch)
• Overflow Detection Switch - Dual Function NO and NC Operation (Set to No from Factory for Equipment Shut Down Connection)

Specifications

• Type: Automatic, Vertical Centrifugal
• Reservoir Inlet Size: (2) 1-1/8 Inch
• Discharge Size: 1/4 Inch x 3/8 Inch Outer Diameter
• End Connection: Female Threaded x Barbed (Outlet)
• Overall Dimensions: 12.11 Inch Length x 6 Inch Width x 10.4 Inch Height
• Flow Rate: 270 GPH at 1 Foot
• Discharge Head: 24 Foot
• Casing Material: ABS Plastic
• Shaft Material: Stainless Steel
• Reservoir Capacity: 1 Gallon
• Housing Material: ABS Plastic
• Impeller Material: Polypropylene
• Power Cord Length: 6 Foot
• Power Rating: 1/18 HP, 148 Kilowatt
• Input Supply Rating: 115 Volt AC 60 Hertz 2.5 Amp
• Temperature Rating: 120 Deg F
• Pressure Rating: 10.4 PSI
• Motor Type: Thermally Protected, Fan Cooled, Concentric
• Inclusions/Features: Automatic Start and Stop Operation, Safety Overflow Switch with (2) 5 Inch Lead Wire, (3) 6 Foot Conductor Cable, (3) Prong Plug
• Application: Air Conditioner, Refrigerant and Dehumidification Equipment, High Efficiency Oil and Gas Fired Condensing Furnace and Boiler Equipment
• Applicable Standard: CSA (Canada and US)
