Features & Benefits

• Stainless Steel Power Element Eliminate Corrosion and Prevent Valve Failure
• Hermetic, Leak-Free Construction
• Compact Size Allow Installation in Limited Space
• Bi-Flow Capability Allows One Valve to Control the Superheat in Both Cooling and Heating Modes for Heat Pump Applications
• Balanced Port Construction Compensates for Changes in Operating Pressures Due to Varying Ambients, Gas Defrost, Heat Reclaim or Widely Varying Evaporator Loads

Specifications

• Type: Hermetic Balanced Port Design, Leak-Free, Bi-Directional, Adjustable Superheat, Straight Through
• Nominal Size: 5/8 Inch x 7/8 Inch
• End Connection: ODF Soldered x ODF Soldered
• End to End Distance: 3.48 Inch
• Pressure Rating: 700 PSIG
• Inclusions/Features: External Equalizer
• Exclusions: Bleed Hole
• Application: Refrigerant Case, Cooler, Freezer, Ice Machine and Air Conditioner System
Capillary Tube Length 5 Foot; Refrigerant Type R-410A; Capacity 7-1/2 Ton; Charge Code Maximum Operating Pressure, Pressure Limiting; Height 3.56 Inch
