Description
Regal Beloit Corporation (Browning) GRIPNOTCH® 1" x 29/32", 180" Outside Circumference, EPDM, Type 8VX, Notched, Cogged V-Belt
Features & Benefits
- Browning 358 Wrapped Belts are Constructed of Neoprene Material Wrapped Top and Bottom
- Operating Temperature Range of -30F to 140F Degrees
- More Horsepower in Less Space-Browning 358 Belts Provide More Horsepower in the Same Span than Conventional ABC Belts
- This Enables You to Reduce Drive Cost
- Greater Horsepower Allows for Smaller Drive Sheaves-Using 358 Belts Can Allow for Smaller Drive Components While Still Meeting the Drive Requirements , Thus Lowering the Overall Drive Cost
- Close Belt Tolerance-Browning Belts Offer the "Code 1" Match Belt System on All Classical and "358" Belts, Allowing Easy Selection of Just One Match Number for Each Belt Size
- This Ensures Tighter than RMA Standards
Specifications
- Type: 8VX, Notched
- Outside Circumference: 200 Inch
- Top Width: 1 Inch
- Thickness: 29/32 Inch
- Material: EPDM
- Application: Agitator, Brick Machinery, Blower and Exhauster, Bucket Elevator, Centrifugal Pump and Compressor, Exciter, Piston Compressor, Light Duty Conveyor, Belt Conveyor, Hammer Mill, Dough Mixer, Paper Mill Beater, Generator, Line Shaft, Laundry Machinery, Machine Tool, Punch Press Shear, Printing Machinery
- Applicable Standard: RMA, ARPM IP-22 Height 0.828 Inch; Efficiency 98 Percent; Operating Temperature Rating 250 Deg F; Reinforcing Cord Material Polyester; Number of Ribs 1
Documents
Specifications
- BrandBrowning
- Belt TypeMultiple V-Belt
- Cross Section Height35/64"
- Cross Section Width1"
- Outside Length Range151-250"
- Size8V
- StyleCogged
- Common Belt Size8VX1800
- MaterialEthylene, Polyester
- Outside Length180 in
- Shipping Height5.3 in
- Shipping Length13.85 in
- Shipping Width13.25 in
- Size8V
- Thickness0.88
- TypeNotched V Belt
- Weight4.84 lb
