Browning 8V2000 Smooth V-Belt

SKU:8V2000
Browning

Browning 8V2000 Smooth V-Belt

SKU:8V2000

    Description

    Regal Beloit Corporation (Browning) GRIPBELTĀ® 1" x 29/32", 200" Outside Circumference, Neoprene, Type 8V, Wrapped V-Belt

    Features & Benefits

    • Browning 358 Wrapped Belts are Constructed of Neoprene Material Wrapped Top and Bottom
    • Operating Temperature Range of -30F to 140F Degrees
    • More Horsepower in Less Space-Browning 358 Belts Provide More Horsepower in the Same Span than Conventional ABC Belts
    • This Enables You to Reduce Drive Cost
    • Greater Horsepower Allows for Smaller Drive Sheaves-Using 358 Belts Can Allow for Smaller Drive Components While Still Meeting the Drive Requirements , Thus Lowering the Overall Drive Cost
    • Close Belt Tolerance-Browning Belts Offer the "Code 1" Match Belt System on All Classical and "358" Belts, Allowing Easy Selection of Just One Match Number for Each Belt Size
    • This Ensures Tighter than RMA Standards

    Specifications

    • Type: 8V
    • Outside Circumference: 224 Inch
    • Top Width: 1 Inch
    • Thickness: 29/32 Inch
    • Material: Neoprene
    • Application: Agitator, Brick Machinery, Blower and Exhauster, Bucket Elevator, Centrifugal Pump and Compressor, Exciter, Piston Compressor, Light Duty Conveyor, Belt Conveyor, Hammer Mill, Dough Mixer, Paper Mill Beater, Generator, Line Shaft, Laundry Machinery, Machine Tool, Punch Press Shear, Printing Machinery
    • Applicable Standard: RMA
    • Efficiency 95 Percent; Operating Temperature Rating 140 Deg F

    Specifications

    • BrandBrowning
    • Belt TypeMultiple V-Belt
    • Cross Section Height7/8"
    • Cross Section Width1"
    • Outside Length Range151-250"
    • Size8V
    • StyleSmooth
    • Common Belt Size8V2000
    • MaterialChloroprene, Polyester
    • Outside Length200 in
    • Size8V
    • Thickness0.88
    • TypeV Belt
    • Weight6.5 lb
