9K Ducted Ductless Indoor HP Performance 208/230V R410A
This product has been superseded by
9K Ducted Ductless Indoor HP Performance 208/230V R410A
Description
40MBDQ09---3
40 = Fan Coil Unit
MB = Model
D = Ducted
Q = Heat Pump
09 = 9,000 BTU
- = Major Series
-- = Not Used
3 = 208/230V - 1 - 60
40 = Fan Coil Unit
MB = Model
D = Ducted
Q = Heat Pump
09 = 9,000 BTU
- = Major Series
-- = Not Used
3 = 208/230V - 1 - 60
Standard Features
- Turbo, Sleep, Follow Me modes
- Low Sound Levels
- ECM Blower Fan
- Fast Installation
- Built in self diagnostic system
- Individual space conditioning
- Easy to use wireless or wired controls
- Advanced service remote included with every unit
- 46°F Heating Setback
Documents
- 2023-2024 Carrier Ductless Product Catalog
- Warranty Card
- Product Data
- 40MBDQDucted Slim Ductless SystemSizes 09 to 58 - Product Data - Carrier
- Submittal 9K
- Catalog
- Carrier eBook Unlocking the Potential of Current Trends and Sustainable Solutions
- Brochure
- Flyer
- 40MBDQ Ducted Style Ductless SystemSizes 09 to 58 - Installation Instructions
- Installation Guide
- KSAIF Wi-Fi Interface Kit for Ductless SystemsOwners Manual
- Owners Manual
Specifications
- BrandCarrier
- BrandCarrier
- FamilyPerformance
- Line Voltage (60Hz)240V
- RefrigerantR410A
- Suction Line Size3/8"
- Tonnage0.25
- Blower Motor Speeds3
- Height7.87 in
- Length19.92 in
- Liquid Line Size1/4 in
- Motor Phase1
- Outside Air ConnectionTrue
- Package Quantity1 ea
- Shipping Height9.5 in
- Shipping Length23 in
- Shipping Point46803, 78264, 92316
- Shipping Weight48 lb
- Shipping Width30.5 in
- Sound Level30 dBA
- Voltage208/230
- Weight40 lb
- Width27.559 in
- Wired Control AvailableTrue
- Wired Control IncludedFalse
- Wireless Control IncludedTrue
Equipment Parts List
There is no data available for this product
