Browning® Classical v-belts are designed to deliver maximum performance and service life. Classical belts feature single wrap design, which provides greater flexibility when using small diameter sheaves. Classical single wrap v-belts also have less fabric overlap, which reduces center distance variation and vibration.

Features & Benefits

• Unique Design Enhances Performance and Provides Increased Horsepower Capacity in a Shorter Center Drive
• Single Fabric Design Allows for the Belt to be More Flexible in Addition, It can Now be Used with Sub-Min Pitch Diameters Sheaves to Reduce Drive Cost
• Reduced Overlap Provides Lower Vibration and Reduced Noise During Operation
• High Strength, Synthetic Fiber Cords Carry the Horsepower Load and Minimize Stretching
• Static Conducting

Specifications

• Type: A, Wrapped
• Outside Circumference: 89.2 Inch
• Top Width: 0.5 Inch
• Thickness: 0.3125 Inch
• Material: Neoprene
• Power Rating: 10.22 HP
• Application: Aggregate and Cement, Agriculture, HVAC, Minerals and Mining, Oil and Gas, Pulp and Paper and Unit Handling
• Pitch Length 88.3 Inch
• Temperature Rating 140 Deg F
• Efficiency 0.95 Percent
