Features & Benefits

• Easy to Read Gage Through Undistorted Plastic Face Permits Viewing from Far Away
• Patented Design Provides Quick Response to Pressure Changes Means No Delay in Assessing Critical Situations
• Durable and Rugged Housing and High Quality Components Combine to Provide Long-Service Life and Minimized Down-Time
• High Accuracy Option is Twice as Accurate as the Standard Magnehelic® Gage

Specifications

• Pressure Gauge Type: Differential
• Minimum Pressure: 0 Inch WC
• Maximum Pressure: 3 Inch WC
• Mounting Type: Vertical
• Display Type: Dial
• Enclosure: IP67
• End Connection: 1/8 Inch Female Threaded
• Connection Location: Side, Back
• Dial Diameter: 4 Inch
• Temperature Rating: 20 to 140 Deg F
• Full Scale Accuracy: +/-3 Percent
• Accuracy: +/-2 Percent
• Application: Filter Monitoring, Air Velocity with Dwyer Pitot Tube, Blower Vacuum Monitoring, Fan Pressure Indication, Duct, Room or Building Pressure, Clean Room Positive Pressure Indication
Material Die-Cast Aluminum Case and Bezel (Housing), Acrylic (Cover); Applicable Standard EU
