Features & Benefits

• Single Coil Family Fits All Valve Sizes
• Extended Ends for Easy Installation
• PTFE O-Ring for Superior External Sealing
• Long-Life Molded Coils

Specifications

• Type: 2-Way, Pilot-Operated, Standard
• Port Connection: 1/8 Inch x 1/8 Inch
• Valve Position: NC
• Temperature Rating: 250 Deg F
• Pressure Rating: 680 PSIG (Maximum Working Pressure), 300 PSIG (Maximum Operating Pressure Differential)
• Media Handled: Liquid, Discharge/Suction Gas
• Applicable Standard: UL, CUL, CRN
Connection Size 3/8 Inch ODF Extended End x 3/8 Inch ODF Extended End; Minimum Operating Pressure Drop 2 PSI; Excludes Coil
