Features & Benefits

• Totally Enclosed Micro Switch Snap Acting Switches Operate on Temperature Rise to Set Point
• Visible Control Point Scale and External Adjustment Screw Permit Easy Setting
• Direct or Well Immersion of the Sensing Element
• Horizontal or Vertical Insertion of the Sensing Element
• Remote Bulb Model May be Used to Sense Air Temperature in Ducts and in Outside Air Sensing Application

Specifications

• Type: 3/8 Inch Diameter x 2-7/8 Inch Length Copper Bulb, 1-1/2 Inch Length Capillary, Direct Horizontal/Vertical Well Immersion, High/Strap-On
• Temperature Range: 100 to 240 Deg F
• Maximum Temperature Rating: 150 Deg F
• Contact Rating: 8 Amp at 120 Volt AC/5.1 Amp at 240 Volt AC (Full Load), 48 Amp at 120 Volt AC/30.6 Amp at 240 Volt AC (Locked Rotor), 0.25 Amp at 0.25 to 12 Volt DC (Millivolt)
• Contact Configuration: SPST, Contact Break on Temperature Rise
• Connection Type: 3/4 Inch Conduit, Screw Terminal
• Application: Boiler, Storage Tank
• Approval: UL, CSA
• Overall Dimension 2 Inch Width x 2-1/8 Inch Depth x 5-5/8 Inch Height
• Mounting Type Horizontal/Vertical
• Includes Bracket for Strap-On Mounting
• Heat Conductive Compound, Stop factory-Set at 240 Deg F
