B DOUBLE V-BELT
B DOUBLE V-BELT
Description
Regal Beloit Corporation (Browning) GRIPBELT® 0.6563", 72.7" Outside Circumference, 70.9" Pitch Length, Neoprene, Type BB, Wrapped V-Belt
Features & Benefits
- Ideal for Multiple Shaft Drives when a Drive Requires Operation of Several Shafts to Run in the Same or Different Directions Double V-Grip belts are the Most Economical Solution
- Ideal for Serpentine Drives
Specifications
- Type: BB
- Outside Circumference: 79.7 Inch
- Top Width: 0.6563 Inch
- Material: Neoprene
- Application: Agitator, Brick Machinery, Blower and Exhauster, Bucket Elevator, Centrifugal Pump and Compressor, Exciter, Piston Compressor, Light Duty Conveyor, Belt Conveyor, Hammer Mill, Dough Mixer, Paper Mill Beater, Generator, Line Shaft, Laundry Machinery, Machine Tool, Punch Press Shear, Printing Machinery Pitch Length 77.9 Inch; Efficiency 95 Percent; Operating Temperature Rating 140 Deg F
Documents
Specifications
- BrandBrowning
- Belt TypeMultiple V-Belt
- Cross Section Height17/32"
- Cross Section Width21/32"
- Outside Length Range71-80"
- Common Belt SizeBB68
- MaterialDiene, Polyester
- Outside Length71 in
- Shipping Height1.95 in
- Shipping Length8.7 in
- Shipping Width8.8 in
- SizeB
- Thickness0.53
- TypeV Belt
- Weight0.9 lb
