Browning® 5V belts are specifically designed to provide maximum horsepower transmission and service life. One of our key features of the product series is EPDM (Ethylene Propylene Diene Monomer). This works to expand temperature range considerably. These Browning® belts operating temperatures for EPDM v-belts are -60°F to +250°F. This expanded range helps ensures long life and reliable performance. They can be counted on even in the most demanding climates and heat sensitive applications. Our exclusive fabric top and bottom design ensure stability and less cord stress, helping to maximize service life.

Features & Benefits

• Oil and Heat Resistant
• Static Conducting
• Ground form Sidewalls Reduce Vibration and Increase Belt and Bearing Life
• Raw Edge Sidewalls Provide a Uniform, Anti-Slip Surface with Greater Flexibility
• Wider Notch Spacing Increases Rigidity and Stability While also Reducing the Stress on the Cord Line
• Fabric Top and Bottom also Increases Rigidity and Stability of the Belt
• Code 1® Belts Can be Matched Using a One-Match System to Help Assure that all the Belts in the Drive Carry an Equal Amount of the Load

Specifications

• Type: 5VX, Notched
• Outside Circumference: 67 Inch
• Top Width: 5/8 Inch
• Thickness: 17/32 Inch
• Material: EPDM
• Application: Agitator, Brick Machinery, Blower and Exhauster, Bucket Elevator, Centrifugal Pump and Compressor, Exciter, Piston Compressor, Light Duty Conveyor, Belt Conveyor, Hammer Mill, Dough Mixer, Paper Mill Beater, Generator, Line Shaft, Laundry Machinery, Machine Tool, Punch Press Shear, Printing Machinery
• Operating Temperature Rating -60 to 250 Deg F
