Specifications

• Item: Compressor, Fixed Speed
• Size: 254 Millimeter Diameter x 558 Millimeter Height
• Color/Finish: Blue
• Used On Item: Air Conditioner
• Applicable Standard: UL, CE
Motor Protection Internal Overload/Electronic Overcurrent; Nominal Capacity 107.85 Kilo BTU/Hour; Refrigerant Type R-22; Voltage Rating 400 Volt AC 50 Hertz, 460 Volt AC 60 Hertz 3-Phase; Current Rating 15.7 Amp (RLA), 130 Amp (LRA), 22 Amp (MCC), 20 Amp (MOC); Suction Connection 1-3/8 Inch ODF Soldered; Discharge Connection 7/8 Inch ODF Soldered; Speed Rating 2900 RPM at 50 Hertz, 3500 RPM at 60 Hertz; Viscosity 32 Centipoise; Enclosure Rating IP54; Connection Type Brazed, Screw
