Features & Benefits

• Sporlan Type S Valve is a Brass Bar Body, Externally Adjustable Valve with ODF Solder Connection
• The Thermostatic Element is Replaceable and the inlet Connection Has a Permanent 12 Mesh Strainer
• This Valve is Designed for Both Air conditioning and Refrigeration Applications

Specifications

• Nominal Size: 5/8 Inch x 7/8 Inch
• End Connection: ODF Soldered x ODF Soldered
• Body Material: Brass Bar
• Temperature Rating: 40 Deg F (Evaporator), 100 Deg F (Liquid)
• Pressure Rating: 450 PSI
• Inclusions/Features: External Equalizer, 12 Mesh Permanent Strainer
• Application: Air Conditioner and Refrigerant
Capillary Tube Length 5 Foot; Refrigerant Type R-22; Capacity 8 Ton; Thermostatic Charge GA; Filter Element Type 83
