Specifications

• BrandWeathermaker
• CFM3167
• Compressor Stage1
• ConfigurationVertical
• Cooling Capacity32400, 35800
• Line Voltage (60Hz)240V
• Nominal Seer14
• RefrigerantR410A
• Suction Line Size7/8"
• Tonnage3
• Voltage (Phase)208/230 V 1-Phase
• Air FlowVertical
• CFM Nominal3167
• CompressorScroll
• Compressor RLA13.6
• Compressor TypeScroll
• Condenser Motor HP0.2
• Condenser Motor Phase1
• Condenser Motor RPM1100 rpm
• Condenser Motor TypePSC
• EER11.5, 13.5
• Fan Diameter24
• Frequency60
• Full Load1.1 amp
• Gas Stages1-Stage
• Height24 78 in
• High PressureFalse
• High Pressure SwitchFalse
• InverterFalse
• LEED CertifiedFalse
• Length31.1875 in
• Liquid Line FittingSweat
• Liquid Line Size3/8
• Liquid Line Size0.375 in
• Locked Rotor79 amp
• Low PressureFalse
• Low Pressure SwitchFalse
• LRA79
• Maximum EER13.5
• Maximum Fuse Size30 amp
• Maximum Piping Length250 Ft.
• Maximum SEER16
• MCA18
• Metering DeviceTXV
• Minimum Ambient Temperature55° F °F
• Minimum EER11.5
• Minimum Heating Ambient Temperature55
• Motor Phase1
• Number Of Fan Blades2
• Outdoor Fan Motor FLA1.1
• Outdoor Number of Rows1
• Package Quantity1 ea
• Rated Load12.8 amp
• Rows1
• SEER14
• Shipping Height26.4375 in
• Shipping Length32.1875 in
• Shipping Point38611, 66350, 78264
• Shipping Weight151 lb
• Shipping Width32.1875 in
• Sound BlanketFalse
• Sound BlanketFalse
• Sound Level75 dBA
• Suction Line FittingSweat in
• Suction Line Size7/8
• UL ListedTrue
• UL RecognizedTrue
• Voltage208/230
• Warranty Offered10-Year Parts Limited Warranty With Timely Registration- Limited Warranty Period Is 5 Years If Not Registered Within 90 Days Of Installation
• Weight134 lb
• Width31.1875 in
