Specifications

• Item: Reciprocating Compressor
• Size: 11.157 Inch Length x 7.298 Inch Width x 8.954 Inch Height
• Used On Item: Refrigerant, Air Conditioner
• Applicable Standard: UL (Canada and US)
Voltage Rating 100 Volt AC 50 Hertz/115 Volt AC 60 Hertz 1-Phase; Current Rating 48 Amp (Locked Rotor), 9.5 Amp at 60 Hertz (Rated Load), 12.2 Amp (Maximum Continuous Current); Power Rating 1/2 HP; Capacity 6300 BTU/Hour; Refrigerant Type R-134A/R-513A; Motor Resistance 0.66 Ohm (Main), 4.6 Ohm (Start); Connection Size 1/2 Inch SAE RL (Suction), 1/4 Inch ODF (Discharge); Oil Type Polyolester; Motor Type CSIR; Motor Starting Torque High; Compressor Cooling Fan; Temperature Rating 65 Deg F (Return Gas), 20 to 55 Deg F (Evaporating), 95 Deg F (Ambient), 115 Deg F (Liquid), 45 Deg F (High/Commercial); Application High Back Pressure
