Browning C85 Smooth V-Belt
Browning C85 Smooth V-Belt
Description
Regal Beloit Corporation (Browning) SUPER GRIPBELT® 7/8" x 17/32", 89.2" Outside Circumference, 87.9" Pitch Length, Neoprene, Type C, Wrapped V-Belt
Features & Benefits
- Only True Dual-Element Time-Delay CC Fuses Specifically Engineered for Motor Branch Circuit Protection
- Provide Type Ii Protection (No Damage) to Both NEMA-Rated and the More Sensitive LEC (International Electromechanical Commission) Type Motor Circuit Components
- Compared to Other UL Listed Fuses, Class CC Dual Element Fuses are the Most Current Limiting, Rating for Rating
- Provide Superior Protection in a Fraction of the Space Required by Other Fuse Classes. — for Example, When 600V Three-Pole, 30 a Class R Fuse Blocks are Replaced by Littelfuse Class CC Fuse Blocks, Panel-Mounting Space is Reduced Approximately 70%
- POWR-PRO® Performance
- Extremely Current Limiting
- RoHS Compliant
Specifications
- Type: Class CC
- Characteristics: Dual Element, Time Delay
- Voltage Rating: 600 Volt AC, 500 Volt DC
- Current Rating: 20 Amp
- Interrupting Rating: 200 Kiloamp (AC, Symmetrical), 20 Kiloamp (DC)
- Terminal Type: Ferrule
- Diameter: 0.41 Inch
- Length: 1.5 Inch
- Approval: UL, CSA, CE RoHS Compliant; Application Motor
Documents
Specifications
- BrandBrowning
- Belt TypeMultiple V-Belt
- Cross Section Height17/32"
- Cross Section Width7/8"
- Outside Length Range81-90"
- SizeC
- StyleSmooth
- Common Belt SizeC85
- MaterialRubber
- Outside Length89 in
- Shipping Height2.7 in
- Shipping Length10.4 in
- Shipping Width10.9 in
- SizeC
- Thickness0.53125
- TypeV Belt
- Weight1.6 lb
