180000 BTU R410A 460-3 Phase Copeland Scroll Compressor
180000 BTU R410A 460-3 Phase Copeland Scroll Compressor
Description
ZP180KCE-TWD-961
Z = Scroll Compressor
P = A/C Duty - R410A
180K = 180000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
W = External Electronic Protection
D = 380/420-3-50 / 460-3-60
961 = Bill of Material Product Variation
Z = Scroll Compressor
P = A/C Duty - R410A
180K = 180000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
W = External Electronic Protection
D = 380/420-3-50 / 460-3-60
961 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Documents
There are no documents available.
Specifications
- BrandCopeland
- Capacity180000-219000
- CFM20.32
- HP15
- Line Voltage (60Hz)480V
- Rated Voltage (60Hz)460
- RefrigerantR410A
- Variety TypeScroll
- ApplicationA/C
- Compressor Capacity180000 btu
- Frequency60
- Height23.3 in
- Length12.63 in
- Liquid Line Size1 1/8 in
- LRA187
- Max RLA23.7
- Max Watts16100
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge8.56 pints
- Shipping Height23.3 in
- Shipping Length12.63 in
- Shipping Point37406
- Shipping Weight235 lb
- Shipping Width13.75 in
- TechnologyScroll
- TypeHerm
- Voltage460
- Weight235 lb
- Width13.75 in
