COMPRESSOR (380V)
COMPRESSOR (380V)
Description
ZP122KCE-TF7-950
Z = Scroll Compressor
P = A/C Duty - R410A
122K = 122000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
7 = 380-3-60
950 = Bill of Material Product Variation
Z = Scroll Compressor
P = A/C Duty - R410A
122K = 122000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
7 = 380-3-60
950 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Specifications
- BrandCopeland
- Capacity124000
- Line Voltage (60Hz)480V
- Rated Voltage (60Hz)380
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Suction Line Size1-1/8"
- Variety TypeScroll
- Compressor Capacity122000 btu
- Frequency50Hz, 60Hz
- Height22 in
- Length11.7 in
- Liquid Line Size7/8 in
- LRA152
- Max RLA23.6
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge5.0625 pints
- Shipping Height22 in
- Shipping Length11.7 in
- Shipping Weight107.6 lb
- Shipping Width10.33 in
- TechnologyScroll
- TypeHerm
- Voltage380
- Weight107.6 lb
- Width10.33 in
