COMPRESSOR (460V)
COMPRESSOR (460V)
Description
ZP122KCE-TFD-950
Z = Scroll Compressor
P = A/C Duty - R410A
122K = 122000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
D = 380/420-3-50 / 460-3-60
950 = Bill of Material Product Variation
Z = Scroll Compressor
P = A/C Duty - R410A
122K = 122000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
D = 380/420-3-50 / 460-3-60
950 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Documents
There are no documents available.
Specifications
- BrandCopeland
- Capacity124000
- HP10.2
- Line Voltage (60Hz)480V
- Rated Voltage (60Hz)460
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Suction Line Size1-1/8"
- Variety TypeScroll
- ApplicationA/C, HP
- Compressor Capacity122000 btu
- Frequency50Hz, 60Hz
- Height22 in
- Length11.7 in
- Liquid Line Size7/8 in
- LRA140.0
- Max RLA17.9
- Max Watts9060
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge5.0625 pints
- Shipping Height14 in
- Shipping Length28 in
- Shipping Point37406
- Shipping Weight145 lb
- Shipping Width17 in
- TechnologyScroll
- TypeHerm
- Voltage460
- Weight107.6 lb
- Width10.33 in
