COMPRESSOR (575V)
COMPRESSOR (575V)
Description
CR42K6-TFE-775
C = Hermetic Reciprocating Compressor
R = R22/R407C, High Temp A/C, H/P
42K = 42000 BTU
6 = Product Family
T = Three Phase
F = Internal Inherent Protection, One Protector, use with contactor
E = 575-3-60
775 = Bill of Material Product Variation
C = Hermetic Reciprocating Compressor
R = R22/R407C, High Temp A/C, H/P
42K = 42000 BTU
6 = Product Family
T = Three Phase
F = Internal Inherent Protection, One Protector, use with contactor
E = 575-3-60
775 = Bill of Material Product Variation
Standard Features
- Rugged reciprocating technology
- Superior efficiency
- Best suited for 55°C high ambient conditions
- Strong liquid handling capability
- Industry leading reliability
- Multiple foot mounting configuration
- UL and IECEE certified
Specifications
- BrandCopeland
- ApplicationAC/HP Duty, High Temperature
- Capacity41700
- Cylinders2
- Line Voltage (60Hz)600V
- Rated Voltage (60Hz)575
- RefrigerantR22
- Refrigerant Oil TypePolyol Ester (POE)
- Suction Line Size3/4"
- Variety TypeReciprocating
- ApplicationAC/HP
- Compressor Capacity42000 btu
- Frequency60Hz
- Height14.6 in
- Length10.2 in
- Liquid Line Size1/2 U 6.2 in
- LRA39
- Max RLA5.2
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge2.6875 pints
- Run CapacitorN/A
- Shipping Height20 in
- Shipping Length15 in
- Shipping Point37406
- Shipping Weight75 lb
- Shipping Width13 in
- Start CapacitorN/A
- TechnologyRecip
- TypeHerm
- Voltage575
- Weight69 lb
- Width9.7 in
