18000 BTU R22 460-3 Phase Copeland Reciprocating Compressor
18000 BTU R22 460-3 Phase Copeland Reciprocating Compressor
Description
Emerson Electric Co. (Copeland) 10.22" x 9.65" x 13.19", 3/4" ODF Soldered Suction, 3/8" ODF Soldered Discharge, 380/420 VAC 50 Hz 3-Phase, 460 VAC 60 Hz, 3.07 RLA, 18000 BTU/Hr, R-22, Hermetic, Reciprocating Compressor with Internal Inherent Protection for Air Conditioner
Features & Benefits
- 6th Generation Fixed Speed Reciprocating Compressor
Specifications
- Size: 10.22 Inch Length x 9.65 Inch Width x 13.19 Inch Height
- Used On Item: High Temperature Air Conditioner and Heat Pump
- Connection Size 3/4 Inch ODF Soldered (Suction), 3/8 Inch ODF Soldered (Discharge)
- Refrigerant Type R-22
- Nominal Capacity 18000 BTU/Hour
- Voltage Rating 380/420 Volt AC 50 Hertz, 460 Volt AC 60 Hertz 3-Phase
- Current Rating 3.07 Amp (RLA)
- Motor Type 3-Phase
- Cooling Efficiency 10.65 EER
- Includes Internal Inherent Protection
Documents
There are no documents available.
Specifications
- BrandCopeland
- ApplicationAC/HP Duty, High Temperature
- Capacity17700
- Cylinders2
- Discharge ConnectionUp
- Discharge ID1/2"
- Line Voltage (60Hz)480V
- Rated Voltage (60Hz)460
- RefrigerantR22
- Suction ConnectionHorizontal
- Suction ID3/4"
- Suction Line Size3/4"
- Variety TypeReciprocating
- ApplicationA/C
- Compressor Capacity18000 btu
- Compressor EER10.7
- Discharge Line Height5.86
- Frequency60Hz
- Height13.1 in
- Length10.2 in
- Liquid Line Size1/2 in
- LRA23
- Max RLA3
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge2.6875 pints
- RLA3
- Run CapacitorN/A
- Shell Height5.86 in
- Shipping Height20 in
- Shipping Length15 in
- Shipping Weight63 lb
- Shipping Width13 in
- Start CapacitorN/A
- Suction Line Height11.07
- TechnologyRecip
- TypeHerm
- Voltage460
- Weight61 lb
- Width9.7 in
