28000 BTU R22 460-3 Phase Copeland Reciprocating Compressor
28000 BTU R22 460-3 Phase Copeland Reciprocating Compressor
Description
CR28K6E-TFD-775
C = Hermetic Reciprocating Compressor
R = R22/R407C, High Temp A/C, H/P
28K = 28000 BTU
6 = Product Family
E = POE Oil
T = Three Phase
F = Internal Inherent Protection, One Protector, use with contactor
D = 380/420-3-50 / 460-3-60
775 = Bill of Material Product Variation
C = Hermetic Reciprocating Compressor
R = R22/R407C, High Temp A/C, H/P
28K = 28000 BTU
6 = Product Family
E = POE Oil
T = Three Phase
F = Internal Inherent Protection, One Protector, use with contactor
D = 380/420-3-50 / 460-3-60
775 = Bill of Material Product Variation
Standard Features
- Rugged reciprocating technology
- Superior efficiency
- Best suited for 55°C high ambient conditions
- Strong liquid handling capability
- Industry leading reliability
- Multiple foot mounting configuration
- UL and IECEE certified
Replacement for
Specifications
- BrandCopeland
- ApplicationAC/HP Duty, High Temperature
- Capacity28100
- Cylinders2
- Line Voltage (60Hz)480V
- Rated Voltage (60Hz)460
- RefrigerantR22
- Refrigerant Oil TypePolyol Ester (POE)
- Suction Line Size3/4"
- Variety TypeReciprocating
- ApplicationAC/HP
- Compressor Capacity28000 btu
- Frequency50Hz, 60Hz
- Height13.6 in
- Length10.2 in
- Liquid Line Size1/2 U 5.86 in
- LRA34
- Max RLA4.8
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge2.6875 pints
- Run CapacitorN/A
- Shipping Height20 in
- Shipping Length15 in
- Shipping Point37406
- Shipping Weight66 lb
- Shipping Width13 in
- TechnologyRecip
- TypeHerm
- Voltage460
- Weight61 lb
- Width9.7 in
