This product has been superseded by
38000 BTU R22 208/230-3 Phase Copeland Reciprocating Compressor
This product has been superseded by
38000 BTU R22 208/230-3 Phase Copeland Reciprocating Compressor
Description
CR38K6-TF5-920
C = Hermetic Reciprocating Compressor
R = R22/R407C, High Temp A/C, H/P
38K = 38000 BTU
6 = Product Family
T = Three Phase
F = Internal Inherent Protection, One Protector, use with contactor
5 = 200/240-3-50 / 200/230-3-60
920 = Bill of Material Product Variation
C = Hermetic Reciprocating Compressor
R = R22/R407C, High Temp A/C, H/P
38K = 38000 BTU
6 = Product Family
T = Three Phase
F = Internal Inherent Protection, One Protector, use with contactor
5 = 200/240-3-50 / 200/230-3-60
920 = Bill of Material Product Variation
Standard Features
- Rugged reciprocating technology
- Superior efficiency
- Best suited for 55°C high ambient conditions
- Strong liquid handling capability
- Industry leading reliability
- Multiple foot mounting configuration
- UL and IECEE certified
Documents
There are no documents available.
Specifications
- BrandCopeland
- ApplicationAC/HP Duty, High Temperature
- Rated Voltage (60Hz)208/230
- RefrigerantR22
- Variety TypeReciprocating
- Frequency50Hz, 60Hz
- Motor Phase3
Equipment Parts List
There is no data available for this product
