53000 BTU R22 208/230-1 Phase Copeland Reciprocating Compressor
53000 BTU R22 208/230-1 Phase Copeland Reciprocating Compressor
Description
CR53KQE-PFV-970
C = Hermetic Reciprocating Compressor
R = R22/R407C, High Temp A/C, H/P
53K = 53000 BTU
Q = Quiet Model
E = POE Oil
P = Single Phase
F = Internal Inherent Protection, One Protector, use with contactor
V = 200-1-50 / 208/230-1-60
970 = Bill of Material Product Variation
C = Hermetic Reciprocating Compressor
R = R22/R407C, High Temp A/C, H/P
53K = 53000 BTU
Q = Quiet Model
E = POE Oil
P = Single Phase
F = Internal Inherent Protection, One Protector, use with contactor
V = 200-1-50 / 208/230-1-60
970 = Bill of Material Product Variation
Standard Features
- Rugged reciprocating technology
- Superior efficiency
- Best suited for 55°C high ambient conditions
- Strong liquid handling capability
- Industry leading reliability
- Multiple foot mounting configuration
- UL and IECEE certified
Documents
There are no documents available.
Specifications
- BrandCopeland
- ApplicationAC/HP Duty, High Temperature
- Capacity53300
- Cylinders2
- Discharge ConnectionUp
- Discharge ID1/2"
- Line Voltage (60Hz)240V
- Mounting ArrangementA
- Rated Voltage (60Hz)208/230
- RefrigerantR22
- Refrigerant Oil TypePolyol Ester (POE)
- Suction ConnectionUp
- Suction ID7/8"
- Suction Line Size7/8"
- Variety TypeReciprocating
- Compressor Capacity53000 btu
- Discharge Line Height5.86
- Frequency50Hz, 60Hz
- Height14.8 in
- Length10.63 in
- Liquid Line Size1/2 U 5.86 in
- LRA140.0
- Max RLA28.9
- Max Watts4840
- Motor Phase1
- Oil Capacity0 ml
- Oil Recharge2.6875 pints
- Run Capacitor60/440 µF/v
- Shell Height14.8 in
- Shipping Height20 in
- Shipping Length15 in
- Shipping Point37406
- Shipping Weight52 lb
- Shipping Width13 in
- Suction Line Height14.41
- TechnologyRecip
- TypeHerm
- Voltage208/230
- Weight77 lb
- Width9.22 in
