120000 BTU R410A 208/230-3 Phase Copeland Scroll Compressor
120000 BTU R410A 208/230-3 Phase Copeland Scroll Compressor
Description
Emerson Electric Co. (Copeland) Copeland Scroll™ 120000 BTU, 200/220 VAC 50 Hz, 200/230 VAC 60 Hz 3-Phase, 7 to 15 HP, R-410A, 11 EER, 3-Phase 3-Lead Single Voltage Motor, Internal Inherent Protection, Digital Modulation, Scroll Compressor with Polyol Ester Oil for High Temperature and Ultra High Pressure Air Conditioner
Copeland Scroll Digital ZPDKC compressor increases HVAC system efficiency via capacity modulation and provide energy savings by precisely matching compressor output to your heating or cooling needs. This technology is perfect for buildings or rooms which experience widely varying loads or where tight temperature and humidity control are needed.
Features & Benefits
- Commercial Compressor with Mechanical Modulation
- Improved Part-Load Efficiencies
- Infinite Capacity Stages
Specifications
- Item: Compressor, Digital Modulation
- Used On Item: High Temperature and Ultra High Pressure Commercial Air Conditioner Motor Type 3-Phase 3-Lead Single Voltage; Motor Protection Internal Inherent; Nominal Capacity 72000 BTU; Refrigerant Type R-410A; Voltage Rating 380/240 Volt AC 50 Hertz, 460 Volt AC 60 Hertz 3-Phase; Suction Connection 7/8 Inch ODF Soldered; Discharge Connection 1/2 Inch ODF Soldered; Power Rating 4 to 6 HP; Efficiency 10.5 EER; Includes Polyol Ester Oil
Documents
Specifications
- BrandCopeland
- Capacity123000
- Line Voltage (60Hz)240V
- Rated Voltage (60Hz)208/230
- RefrigerantR410A
- Variety TypeScroll
- ApplicationA/C
- Compressor Capacity120000 btu
- Frequency60
- Height21 in
- Length11.54 in
- Liquid Line Size7/8 in
- LRA239
- Max RLA37.1
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge6.625 pints
- Shipping Height16 in
- Shipping Length28.5 in
- Shipping Point37406
- Shipping Weight178 lb
- Shipping Width18 in
- TechnologyScroll
- TypeHerm
- Voltage200/220/230
- Weight136 lb
- Width11.23 in
