120000 BTU R410A 460-3 Phase Copeland Scroll Compressor
120000 BTU R410A 460-3 Phase Copeland Scroll Compressor
Description
ZPD120KCE-TFD-950
Z = Scroll Compressor
P = A/C Duty - R410A
D = Digital
120K = 120000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
D = 380/420-3-50 / 460-3-60
950 = Bill of Material Product Variation
Z = Scroll Compressor
P = A/C Duty - R410A
D = Digital
120K = 120000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
D = 380/420-3-50 / 460-3-60
950 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Documents
Specifications
- BrandCopeland
- Capacity123000
- HP10
- Line Voltage (60Hz)480V
- Rated Voltage (60Hz)460
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Variety TypeScroll
- ApplicationA/C, HP
- Compressor Capacity120000 btu
- Frequency50Hz, 60Hz
- Height21 in
- Length11.54 in
- Liquid Line Size7/8 in
- LRA125.0
- Max RLA20
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge6.625 pints
- Shipping Height15 in
- Shipping Length26.5 in
- Shipping Point37406
- Shipping Weight160 lb
- Shipping Width15 in
- Suction Line Size1 3/8 in
- TechnologyScroll
- TypeHerm
- Voltage380/420/460
- Weight136 lb
- Width11.23 in
