Carlyle

Service Compressor 400/460V (50Hz-60Hz) Medium Temperature-Refrigeration Duty

SKU:06DM8087GA3600
Carlyle

Service Compressor 400/460V (50Hz-60Hz) Medium Temperature-Refrigeration Duty

SKU:06DM8087GA3600

    Description

    06DM8087GA3600
    06DM = Service Compressor - Replacement for new 06DA, DM without unloading
    8 = Motor Size
    08 = Displacement in CFM at 1750 RPM
    7 = Service Compressor, New Manufactured
    G = Pump End Suction Service Valve, Plain, 225D
    A = With Internal Thermostat and External Overloads
    36 = 400/460-3 (50/60)
    0 = 1st Generation Suction Cut-Off Unloading
    0 = Single Pack Base Unit Unpackages

    Standard Features

    • High-flow, automatically reversible oil pump provides positive-displacement oil lubrication.
    • Crankcase venting system equalizes pressure during startup and assures oil return to sump.
    • Oversize sump holds extra oil in crankcase to prevent levels dropping below safe lubrication range during flooded starts.
    • Contoured pistons lower cylinder clearances to increase compressor capacity and efficiency.
    • High-efficiency valves provide increased refrigerant flow and lower pressure drops.
    • Electronic oil-pressure switch.
    Note: Compressor Core Credit applied Upon Return of Compressor Body. Core Credit Pricing Varies by Model.

    Specifications

    • BrandCarlyle
    • ApplicationMedium Temperature, Refrigeration Duty
    • CFM Displacement08
    • Cylinders2
    • DesignManufactured Service
    • RefrigerantR134A, R22, R404A, R407A, R407C, R407F, R448A, R449A, R450A, R452A, R500, R502, R507, R513A
    • Suction Line Size7/8"
    • Variety Type06D/6D - Reciprocating
    • Voltage400/460
    • Frequency50Hz, 60Hz
    • LRA35.5
    • Max RLA5.6
    • Motor Phase3
    • Shipping Height23 in
    • Shipping Length26 in
    • Shipping Point37406
    • Shipping Weight165 lb
    • Shipping Width20 in
