SCROLL COMPRESSOR (DIGITAL)
SCROLL COMPRESSOR (DIGITAL)
Description
ZPD42K5E-TF5-830
Z = Scroll Compressor
P = A/C Duty - R410A
D = Digital
42K = 42000 BTU
5 = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
5 = 200/230-3 (50/60)
830 = Bill of Material Product Variation
Z = Scroll Compressor
P = A/C Duty - R410A
D = Digital
42K = 42000 BTU
5 = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
5 = 200/230-3 (50/60)
830 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Documents
Specifications
- BrandCopeland
- Capacity43000
- Discharge ConnectionStub
- Discharge ID1/2"
- Line Voltage (60Hz)240V
- Mounting ArrangementA
- Rated Voltage (60Hz)208/230
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Suction ConnectionStub
- Suction ID25/32"
- Suction Line Size7/8"
- Variety TypeScroll
- ApplicationA/C
- Compressor Capacity42000 btu
- Frequency50Hz, 60Hz
- Height17.66 in
- Length9.57 in
- Liquid Line Size1/2 in
- LRA110.0
- Max RLA17.9
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge2.375 pints
- Shell Height17.7 in
- Shipping Height23 in
- Shipping Length17 in
- Shipping Point37406
- Shipping Weight158 lb
- Shipping Width31 in
- TechnologyScroll
- TypeHerm
- Voltage200/220/230
- Weight72.2 lb
- Width9.57 in
