Features & Benefits

• The Entire Scroll Compression Process is Illustrated Below
• The Centre of the Orbiting Scroll Trace a Circular Path Around the Centre of the Fixed Scroll
• This Movement Create Compression Pocket Between the Two Scroll Element
• Low Pressure Suction Gas is Trapped within Each Crescent Shaped Pocket as it Forms Continuous Motion of the Orbiting Scroll Serve to Seal the Pocket, Which Decrease in Volume as the Pocket Move Toward the Centre of the Scroll Set, with Corresponding Increase in Gas Pressure
• Maximum Compression is Achieved, as the Pocket Reache the Discharge Port at the Centre
• Made in USA

Specifications

• Used On Item: Air Conditioner
• Applicable Standard: UL (Canada and US), CE
• Refrigerant Type R-407C
• Lubricant Type PVE
• Nominal Capacity 75 BTU/Hour at 60 Hertz
• Voltage Rating 200 to 220 Volt AC 50 Hertz 3-Phase, 208 to 230 Volt AC 60 Hertz 3-Phase
• Motor Protection Type Internal
• Connection Type Brazed
• Terminal Type Spade
• Model Variation Design Optimized for 7.2/54.4 Deg C
• Application High Temperature/Air Conditioning
