Savings now and for a lifetime Danfoss air conditioning compressors reduce costs across the entire product lifespan in the application. They support system design for high efficiency performance and for the use of alternative refrigerants for light commercial, commercial and industrial HVAC applications such as rooftops units, chillers, process cooling, packaged units etc. Development costs The versatility, flexibility and efficiency of Danfoss air conditioning compressors ensure competitive design costs and shorter development times for HVAC units ranging from 2.5 to 350 tons. This offer includes the pioneering oil-free centrifugal Danfoss Turbocor Compressors as well as Danfoss Scrolls with Danfoss Intermediate Discharge Valves (IDVs), that optimize part-load efficiency, are backward compatible and minimize redesign costs. Running costs Danfoss technologies offer the widest portfolio for superior full and part-load efficiencies to reduce the running costs of the system. Staged and continuous modulation with state-of-the-art manifolding and variable speed solutions and highly efficient compression technologies, including oil-free magnetic bearing centrifugal and scrolls with IDVs, are Danfoss options to achieve the most demanding energy efficiency standards. Service costs The reliability, design and long working life of Danfoss compressors minimize maintenance and servicing costs while eliminating unplanned downtime. Frequent on/off cycling, high ambient start-up, defrost mode, low superheat conditions, high ambient operations and oil return at part-load conditions can all have severe effects on the entire lifetime of compressor applications. Building on this knowledge, Danfoss reliability and R&D teams use advanced tools and labs to improve compressor durability in many different applications.

Features & Benefits

• Commercial (3-Phase Only) Fixed Speed Compressor

Specifications

• Item: Compressor
• Used On Item: High Temperature and Ultra High Pressure Commercial Air Conditioner
Motor Type 3-Phase 3-Lead Single Voltage; Motor Protection Internal Inherent; Nominal Capacity 50000 BTU; Refrigerant Type R-410A; Voltage Rating 380/240 Volt AC 50 Hertz, 460 Volt AC 60 Hertz 3-Phase; Suction Connection 7/8 Inch ODF Soldered; Discharge Connection 1/2 Inch ODF Soldered; Power Rating 4 to 6 HP; Efficiency 10.5 EER; Includes Polyol Ester Oil
