SCROLL COMPRESSOR
SCROLL COMPRESSOR
Description
ZP137KCE-TF7-855
Z = Scroll Compressor
P = A/C Duty - R410A
137K = 137000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
7 = 380-3-60
855 = Bill of Material Product Variation
Z = Scroll Compressor
P = A/C Duty - R410A
137K = 137000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
7 = 380-3-60
855 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Specifications
- BrandCopeland
- Capacity137000
- Line Voltage (60Hz)480V
- Rated Voltage (60Hz)380
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Variety TypeScroll
- Compressor Capacity137000 btu
- Frequency50Hz, 60Hz
- Height21 in
- Length10.38 in
- Liquid Line Size7/8 H 19.73 in
- LRA145
- Max RLA26.4
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge6.625 pints
- Run CapacitorN/A
- Shipping Height32 in
- Shipping Length32 in
- Shipping Point37406
- Shipping Weight155 lb
- Shipping Width38 in
- TechnologyScroll
- TypeHerm
- Voltage380
- Weight138 lb
- Width11.23 in
