SCROLL COMPRESSOR
SCROLL COMPRESSOR
Description
ZP24K5E-TFE-899
Z = Scroll Compressor
P = A/C Duty - R410A
24K = 24000 BTU
5 = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
E = 500-3-50 / 575-3-60
899 = Bill of Material Product Variation
Z = Scroll Compressor
P = A/C Duty - R410A
24K = 24000 BTU
5 = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
E = 500-3-50 / 575-3-60
899 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Specifications
- BrandCopeland
- Capacity24000
- Line Voltage (60Hz)600V
- Rated Voltage (60Hz)575
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Suction Line Size3/4"
- Variety TypeScroll
- ApplicationAC
- Compressor Capacity24000 btu
- Frequency50Hz, 60Hz
- Height15.27 in
- Length9.56 in
- Liquid Line Size1/2 H 14.15 in
- LRA23.7
- Max RLA3.7
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge1.3125 pints
- Run CapacitorN/A
- Shipping Height20 in
- Shipping Length14 in
- Shipping Point37406
- Shipping Weight50 lb
- Shipping Width14 in
- Start CapacitorN/A
- TechnologyScroll
- TypeHerm
- Voltage575
- Weight47.4 lb
- Width9.56 in
