SCROLL COMPRESSOR
SCROLL COMPRESSOR
Description
ZP295KCE-TED-750
Z = Scroll Compressor
P = A/C Duty - R410A
295K = 295000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
E = External Module with CoreSenseTM Diagnostics/ Protection
D = 380/420-3-50 / 460-3-60
750 = Bill of Material Product Variation
Z = Scroll Compressor
P = A/C Duty - R410A
295K = 295000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
E = External Module with CoreSenseTM Diagnostics/ Protection
D = 380/420-3-50 / 460-3-60
750 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Specifications
- BrandCopeland
- Capacity294000
- Line Voltage (60Hz)480V
- Rated Voltage (60Hz)460
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Variety TypeScroll
- ApplicationA/C, HP
- Compressor Capacity29000 btu
- Frequency50Hz, 60Hz
- Height28.5 in
- Length17.6 in
- Liquid Line Size1 3/8 in
- LRA272.0
- Max RLA46.7
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge13.75 pints
- Run CapacitorN/A
- Shipping Height36 in
- Shipping Length30 in
- Shipping Point37406
- Shipping Weight393 lb
- Shipping Width30 in
- Suction Line Size1 5/8 in
- TechnologyScroll
- TypeHerm
- Voltage460
- Weight353 lb
- Width18.1 in
