SCROLL COMPRESSOR
SCROLL COMPRESSOR
Description
ZP34K5E-PFV-83Y
Z = Scroll Compressor
P = A/C Duty - R410A
34K = 34000 BTU
5 = Model Series
E = POE Oil - AK/DA or 3MA
P = 1 Phase
F = Internal Inherent Protection - One protector, use with contactor
V = 200-1-50 / 208/230-1-60
83Y = Bill of Material Product Variation
Z = Scroll Compressor
P = A/C Duty - R410A
34K = 34000 BTU
5 = Model Series
E = POE Oil - AK/DA or 3MA
P = 1 Phase
F = Internal Inherent Protection - One protector, use with contactor
V = 200-1-50 / 208/230-1-60
83Y = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Documents
There are no documents available.
Specifications
- BrandCopeland
- Capacity34500
- Line Voltage (60Hz)240V
- Rated Voltage (60Hz)208/230
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Suction Line Size7/8"
- Variety TypeScroll
- Compressor Capacity34000 btu
- Frequency60Hz
- Height16.94 in
- Length9.56 in
- Liquid Line Size1/2 in
- LRA112
- Max RLA20
- Motor Phase1
- Oil Capacity0 ml
- Oil Recharge2.375 pints
- Shipping Height24 in
- Shipping Length25 in
- Shipping Point37406
- Shipping Weight77.41 lb
- Shipping Width25 in
- TechnologyScroll
- TypeHerm
- Voltage208/230
- Weight71.2 lb
- Width9.56 in
