182000 BTU R410A 460-3 Phase Copeland Scroll Compressor
182000 BTU R410A 460-3 Phase Copeland Scroll Compressor
Description
Emerson Electric Co. (Copeland) Scroll™ 380 to 240 VAC 50 Hz 3-Phase, 460 VAC 60 Hz, 182000 BTU/Hr, R-410A, Scroll Compressor with POE Oil and External Enhanced Protection for Air Conditioner
Specifications
- Used On Item: High Temperature Air Conditioner
- Modulation Digital
- Refrigerant Type R-410A
- Nominal Capacity 182000 BTU/Hour
- Voltage Rating 380 to 240 Volt 50 Hertz, 460 Volt AC 60 Hertz 3-Phase
- Motor Type 3-Lead 3-Phase
- Cooling Efficiency 11 EER
- Includes POE Oil, External Enhanced Protection
Documents
Specifications
- BrandCopeland
- Capacity183000
- CFM20.65
- Discharge ConnectionStub
- Discharge ID7/8"
- HP4.5
- Line Voltage (60Hz)480V
- Mounting ArrangementA
- Rated Voltage (60Hz)460
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Suction ConnectionStub
- Suction ID1-3/8"
- Variety TypeScroll
- ApplicationA/C, HP
- Compressor Capacity182000 btu
- Frequency50Hz, 60Hz
- Height22.21 in
- Length12.93 in
- Liquid Line Size7/8 in
- LRA173.0
- Max RLA30
- Max Watts4742
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge6.875 pints
- Run CapacitorN/A
- Shell Height22.2 in
- Shipping Height28 in
- Shipping Length19 in
- Shipping Point37406
- Shipping Weight160 lb
- Shipping Width16 in
- Suction Line Size1 3/8 in
- TechnologyScroll
- TypeHerm
- Voltage460
- Weight147 lb
- Width11.73 in
