120000 BTU R410A 208/230-3 Phase Copeland Scroll Compressor
120000 BTU R410A 208/230-3 Phase Copeland Scroll Compressor
Description
ZP120KCE-TF5-950
Z = Scroll Compressor
P = A/C Duty - R410A
120K = 120000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
5 = 200/230-3 (50/60)
950 = Bill of Material Product Variation
Z = Scroll Compressor
P = A/C Duty - R410A
120K = 120000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
5 = 200/230-3 (50/60)
950 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Documents
There are no documents available.
Specifications
- BrandCopeland
- Capacity123000
- Discharge ConnectionHorizontal
- Discharge ID7/8"
- HP10
- Line Voltage (60Hz)240V
- Mounting ArrangementA
- Rated Voltage (60Hz)208/230
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Suction ConnectionHorizontal
- Suction ID1-3/8"
- Variety TypeScroll
- ApplicationAC/HP
- Compressor Capacity120000 btu
- Discharge Line Height19.73
- Frequency50Hz, 60Hz
- Height21.0 in
- Length10.38 in
- Liquid Line Size7/8 H 19.73 in
- LRA239.0
- Max RLA37.1
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge6.625 pints
- Run CapacitorN/A
- Shell Height21 in
- Shipping Height32 in
- Shipping Length32 in
- Shipping Point37406
- Shipping Weight152 lb
- Shipping Width38 in
- Suction Line Height4.81
- TechnologyScroll
- TypeHerm
- Voltage208/230
- Weight135 lb
- Width11.23 in
