154000 BTU R410A 575-3 Phase Copeland Scroll Compressor
154000 BTU R410A 575-3 Phase Copeland Scroll Compressor
Description
ZP154KCE-TEE-965
Z = Scroll Compressor
P = A/C Duty - R410A
154K = 154000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
E = External Module with CoreSenseTM Diagnostics/ Protection
E = 500-3-50 / 575-3-60
965 = Bill of Material Product Variation
Z = Scroll Compressor
P = A/C Duty - R410A
154K = 154000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
E = External Module with CoreSenseTM Diagnostics/ Protection
E = 500-3-50 / 575-3-60
965 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Specifications
- BrandCopeland
- Capacity138000-155000
- HP15
- Line Voltage (60Hz)600V
- Rated Voltage (60Hz)575
- RefrigerantR410A
- Variety TypeScroll
- ApplicationA/C
- Compressor Capacity154000 btu
- Frequency60
- Height22.21 in
- Length12.93 in
- LRA109
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge7.125 pints
- Shipping Height32 in
- Shipping Length32 in
- Shipping Weight190 lb
- Shipping Width38 in
- Suction Line Size1-3/4 in
- TechnologyScroll
- TypeHerm
- Voltage575
- Weight143 lb
- Width11.73 in
