23000 BTU R410A 575-3 Phase Copeland Scroll Compressor
23000 BTU R410A 575-3 Phase Copeland Scroll Compressor
Description
ZP235KCE-TWE-750
Z = Scroll Compressor
P = A/C Duty - R410A
235K = 235000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
W = External Electronic Protection
E = 500-3-50 / 575-3-60
750 = Bill of Material Product Variation
Z = Scroll Compressor
P = A/C Duty - R410A
235K = 235000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
W = External Electronic Protection
E = 500-3-50 / 575-3-60
750 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Specifications
- BrandCopeland
- Capacity235000
- Discharge ConnectionHorizontal
- Discharge ID1-3/8"
- Line Voltage (60Hz)600V
- Rated Voltage (60Hz)575
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Suction ConnectionHorizontal
- Suction ID1-5/8"
- Variety TypeScroll
- ApplicationA/C
- Compressor Capacity23000 btu
- Compressor EER11.1
- Discharge Line Height26.26
- Frequency60Hz
- Height28.6 in
- Liquid Line Size1 3/8 in
- LRA180
- Max RLA27.4
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge9.25 pints
- RLA27.4
- Shipping Height35.2 in
- Shipping Length30 in
- Shipping Point37406
- Shipping Weight359 lb
- Shipping Width30 in
- Suction Line Height13.13
- TechnologyScroll
- TypeHerm
- Voltage575
- Weight310 lb
