This product has been superseded by
26000 BTU R410A 208/230-3 Phase Copeland Scroll Compressor
This product has been superseded by
26000 BTU R410A 208/230-3 Phase Copeland Scroll Compressor
Description
ZP26K3E-TF5-930
Z = Scroll Compressor
P = A/C Duty - R410A
26K = 26000 BTU
3 = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
5 = 200/230-3 (50/60)
930 = Bill of Material Product Variation
Z = Scroll Compressor
P = A/C Duty - R410A
26K = 26000 BTU
3 = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
5 = 200/230-3 (50/60)
930 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Documents
There are no documents available.
Specifications
- BrandCopeland
- Line Voltage (60Hz)240V
- Rated Voltage (60Hz)208/230
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Variety TypeScroll
- Compressor Capacity26000 btu
- Frequency50Hz, 60Hz
- Motor Phase3
- Shipping Height20 in
- Shipping Length15 in
- Shipping Weight80 lb
- Shipping Width14 in
