31000 BTU R410A 208/230-1 Phase Copeland Scroll Compressor
31000 BTU R410A 208/230-1 Phase Copeland Scroll Compressor
Description
Emerson Electric Co. (Copeland) Copeland Scroll™ 31000 BTU, 200 VAC 50 Hz, 208/230 VAC 60 Hz 1-Phase, 2 to 3.5 HP, R-410A, 10.5 EER, 1-Phase Permanent Split Capacitor Motor, Internal Inherent Protection, Scroll Compressor with Polyol Ester Oil for Air Conditioner
Copeland Scroll ZPK6 fixed capacity compressor for residential applications supports the higher performance required to meet minimum efficiency standards. It is built upon the robust ZPK5 platform which ensures excellent reliability and quality that is proven by over 100 million compressors sold to date.
Specifications
- Item: Hot Water Coil
- Used On Item: B Series Air Handler
- Used On Model/Brand: 31/37/42/48 Number of Rows 4
Documents
Specifications
- BrandCopeland
- Capacity42500
- CFM3.63
- HP2.5
- Line Voltage (60Hz)240V
- Rated Voltage (60Hz)208/230
- RefrigerantR410A
- Suction Line Size3/4"
- Variety TypeScroll
- ApplicationA/C
- Compressor Capacity31000 btu
- Frequency60
- Height15.27 in
- Length9.56 in
- Liquid Line Size1/2 in
- LRA83.9
- Max RLA17.1
- Max Watts2980
- Motor Phase1
- Oil Capacity0 ml
- Oil Recharge1.31 pints
- Run Capacitor45/370
- Shipping Height21 in
- Shipping Length13 in
- Shipping Point37406
- Shipping Weight62 lb
- Shipping Width14 in
- TechnologyScroll
- TypeHerm
- Voltage208/230
- Weight49 lb
- Width9.56 in
