34000 BTU R410A 208/230-1 Phase Copeland Scroll Compressor
34000 BTU R410A 208/230-1 Phase Copeland Scroll Compressor
Description
Emerson Electric Co. (Copeland) Scroll™ 7/8" ODF Soldered Suction, 1/2" ODF Soldered Discharge, 200 VAC 50 Hz 1-Phase, 208 to 230 VAC 60 Hz, 34000 BTU/Hr, R-410A, Scroll Compressor with POE Oil and Internal Inherent Protection for Air Conditioner
Specifications
- Used On Item: High Temperature Air Conditioner
- Connection Size 7/8 Inch ODF Soldered (Suction), 1/2 Inch ODF Soldered (Discharge)
- Refrigerant Type R-410A
- Nominal Capacity 34000 BTU/Hour
- Voltage Rating 200 Volt AC 50 Hertz, 208 to 230 Volt AC 60 Hertz 1-Phase
- Motor Type 1-Phase PSC
- Cooling Efficiency 10.7 EER
- Includes POE Oil, Internal Inherent Protection
Documents
There are no documents available.
Specifications
- BrandCopeland
- Capacity34600
- Line Voltage (60Hz)240V
- Rated Voltage (60Hz)208/230
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Suction Line Size7/8"
- Variety TypeScroll
- ApplicationA/C
- Compressor Capacity34000 btu
- Frequency50Hz, 60Hz
- Height16.94 in
- Length9.56 in
- Liquid Line Size1/2 in
- LRA109.0
- Max RLA18.6
- Motor Phase1
- Oil Capacity0 ml
- Oil Recharge2.25 pints
- Run Capacitor45/370
- Shipping Height20 in
- Shipping Length15 in
- Shipping Point37406
- Shipping Weight74 lb
- Shipping Width13 in
- TechnologyScroll
- TypeHerm
- Voltage208/230
- Weight64 lb
- Width9.56 in
