38000 BTU R410A 460-3 Phase Copeland Scroll Compressor
38000 BTU R410A 460-3 Phase Copeland Scroll Compressor
Description
ZP38K3E-TFD-830
Z = Scroll Compressor
P = A/C Duty - R410A
38K = 38000 BTU
3 = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
D = 380/420-3-50 / 460-3-60
830 = Bill of Material Product Variation
Z = Scroll Compressor
P = A/C Duty - R410A
38K = 38000 BTU
3 = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
D = 380/420-3-50 / 460-3-60
830 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Specifications
- BrandCopeland
- Capacity37600
- Discharge ConnectionHorizontal
- Discharge ID1/2"
- Line Voltage (60Hz)480V
- Rated Voltage (60Hz)460
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Suction ConnectionHorizontal
- Suction ID3/4"
- Suction Line Size3/4"
- Variety TypeScroll
- ApplicationAC/HP
- Compressor Capacity38000 btu
- Compressor EER10
- Discharge Line Height14.62
- Frequency60Hz
- Height16.1 in
- Liquid Line Size1/2 H 14.62 in
- LRA46
- Max RLA7.9
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge2.375 pints
- RLA7.9
- Run CapacitorN/A
- Shipping Height20 in
- Shipping Length15 in
- Shipping Point37406
- Shipping Weight68 lb
- Shipping Width13 in
- Suction Line Height10.94
- TechnologyScroll
- TypeHerm
- Voltage460
- Weight66 lb
