57000 BTU R410A 208/230-3 Phase Copeland Scroll Compressor
57000 BTU R410A 208/230-3 Phase Copeland Scroll Compressor
Description
ZP57K5E-TF5-830
Z = Scroll Compressor
P = A/C Duty - R410A
57K = 57000 BTU
5 = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
5 = 200/230-3 (50/60)
830 = Bill of Material Product Variation
Z = Scroll Compressor
P = A/C Duty - R410A
57K = 57000 BTU
5 = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
5 = 200/230-3 (50/60)
830 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Specifications
- BrandCopeland
- Capacity57500
- Discharge ConnectionHorizontal
- Discharge ID1/2"
- Line Voltage (60Hz)240V
- Mounting ArrangementA
- Rated Voltage (60Hz)208/230
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Suction ConnectionHorizontal
- Suction ID7/8"
- Suction Line Size7/8"
- Variety TypeScroll
- ApplicationA/C
- Compressor Capacity57000 btu
- Discharge Line Height15.87
- Frequency50Hz, 60Hz
- Height16.9 in
- Length9.69 in
- Liquid Line Size1/2 H 15.87 in
- LRA136
- Max RLA21.4
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge2.375 pints
- Run CapacitorN/A
- Shell Height16.9 in
- Shipping Height21 in
- Shipping Length13.25 in
- Shipping Point37406
- Shipping Weight72 lb
- Shipping Width14.5 in
- Start CapacitorN/A
- Suction Line Height11.68
- TechnologyScroll
- TypeHerm
- Voltage208/230
- Weight75.6 lb
- Width9.69 in
