Copeland

90000 BTU R410A 460-3 Phase Copeland Scroll Compressor

SKU:ZP90KCE-TFD-950
Copeland

90000 BTU R410A 460-3 Phase Copeland Scroll Compressor

SKU:ZP90KCE-TFD-950

    Description

    ZP90KCE-TFD-950
    Z = Scroll Compressor
    P = A/C Duty - R410A
    90K = 90000 BTU
    C = Model Series
    E = POE Oil - AK/DA or 3MA
    T = 3 Phase
    F = Internal Inherent Protection - One protector, use with contactor
    D = 380/420-3-50 / 460-3-60
    950 = Bill of Material Product Variation

    Standard Features

    • High efficiency – EER 11.0 plus
    • Low Noise & Vibration levels
    • Inherent motor protection
    • Centrifugal oil pump
    • For Heat Pump & Air Conditioning duty
    • POE Oil

    Documents

    There are no documents available.

    Specifications

    • BrandCopeland
    • BrandCopeland
    • Capacity90500
    • Discharge ConnectionHorizontal
    • Discharge ID7/8"
    • HP7.5
    • Line Voltage (60Hz)480V
    • Mounting ArrangementA
    • Rated Voltage (60Hz)460
    • RefrigerantR410A
    • Refrigerant Oil TypePolyol Ester (POE)
    • Suction ConnectionHorizontal
    • Suction ID1-1/8"
    • Suction Line Size1-1/8"
    • Variety TypeScroll
    • ApplicationAC/HP
    • Compressor Capacity90000 btu
    • Discharge Line Height17.49
    • Frequency50Hz, 60Hz
    • Height18.8 in
    • Length10.38 in
    • Liquid Line Size7/8 H 17.49 in
    • LRA95.0
    • Max RLA16.4
    • Max Watts6950
    • Motor Phase3
    • Oil Capacity0 ml
    • Oil Recharge5.0625 pints
    • Run CapacitorN/A
    • Shell Height18.8 in
    • Shipping Height32 in
    • Shipping Length32 in
    • Shipping Point37406
    • Shipping Weight142 lb
    • Shipping Width38 in
    • Suction Line Height3.69
    • TechnologyScroll
    • TypeHerm
    • Voltage460
    • Weight127 lb
    • Width11.23 in
