91000 BTU R410A 460-3 Phase Copeland Scroll Compressor
91000 BTU R410A 460-3 Phase Copeland Scroll Compressor
Description
ZP91KCE-TFD-950
Z = Scroll Compressor
P = A/C Duty - R410A
91K = 91000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
D = 380/420-3-50 / 460-3-60
950 = Bill of Material Product Variation
Z = Scroll Compressor
P = A/C Duty - R410A
91K = 91000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
D = 380/420-3-50 / 460-3-60
950 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Documents
There are no documents available.
Specifications
- BrandCopeland
- Capacity90500
- Discharge ConnectionHorizontal
- Discharge ID3/4"
- HP7.6
- Line Voltage (60Hz)480V
- Mounting ArrangementA
- Rated Voltage (60Hz)460
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Suction ConnectionHorizontal
- Suction ID7/8"
- Suction Line Size7/8"
- Variety TypeScroll
- ApplicationAC/HP
- Compressor Capacity91000 btu
- Discharge Line Height16.17
- Frequency50Hz, 60Hz
- Height17.5 in
- Length9.57 in
- Liquid Line Size3/4 H 16.17 in
- LRA100.0
- Max RLA14.3
- Max Watts6790
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge3.5 pints
- Run CapacitorN/A
- Shell Height17.5 in
- Shipping Height24 in
- Shipping Length22 in
- Shipping Point37406
- Shipping Weight94 lb
- Shipping Width33 in
- Suction Line Height11.73
- TechnologyScroll
- TypeHerm
- Voltage460
- Weight90 lb
- Width9.77 in
