137000 BTU R410A 208/230-3 Phase Copeland Scroll Compressor
137000 BTU R410A 208/230-3 Phase Copeland Scroll Compressor
Description
ZPD137KCE-TF5-950
Z = Scroll Compressor
P = A/C Duty - R410A
D = Digital
137K = 137000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
5 = 200/230-3 (50/60)
950 = Bill of Material Product Variation
Z = Scroll Compressor
P = A/C Duty - R410A
D = Digital
137K = 137000 BTU
C = Model Series
E = POE Oil - AK/DA or 3MA
T = 3 Phase
F = Internal Inherent Protection - One protector, use with contactor
5 = 200/230-3 (50/60)
950 = Bill of Material Product Variation
Standard Features
- High efficiency – EER 11.0 plus
- Low Noise & Vibration levels
- Inherent motor protection
- Centrifugal oil pump
- For Heat Pump & Air Conditioning duty
- POE Oil
Documents
Specifications
- BrandCopeland
- Capacity137500
- Line Voltage (60Hz)240V
- Rated Voltage (60Hz)208/230
- RefrigerantR410A
- Refrigerant Oil TypePolyol Ester (POE)
- Variety TypeScroll
- ApplicationA/C
- Compressor Capacity137000 btu
- Frequency50Hz, 60Hz
- Height21 in
- Length11.54 in
- Liquid Line Size7/8 in
- LRA245.0
- Max RLA53.6
- Motor Phase3
- Oil Capacity0 ml
- Oil Recharge6.625 pints
- Shipping Height32 in
- Shipping Length32 in
- Shipping Point37406
- Shipping Weight179 lb
- Shipping Width38 in
- Suction Line Size1 3/8 in
- TechnologyScroll
- TypeHerm
- Voltage200/220/230
- Weight135 lb
- Width11.23 in
